KOm Cable separator
example of assembly
Cable separator KOM 50 Cable separator KOM 100
H (hight of separator) 48 mm H (hight of separator) 98 mm
intended for cable trays of 50 mm height intended for cable trays of 100 mm height
Product: Cable separator KOM
Manufacturer: ARKYS Ltd., Podstranska 1, 627 00 Brno
Technical features:
Material – plastic
Surface finish of the bolt – cold galvanized
Use:
The cable separator KOM is used prior to the insertion of the cables for temporary division of the space (e.g. power circuits/weak current)
in a plurality of chambers, which makes the following bundling of cables easier.
The advantage of these KOM separators resides in that they have been designed for being fixed in any part of the double beam of the tray
over its whole width, thus facilitating the installation and the transparency for a plurality of cable chambers.
When the bundling is ready, the separators KOM can be removed and then used anew.
Specifications:
Height – 48 and 98 mm
Diameter – 15 mm
components shown in the figure are included in the package
