junction box holder
example of assembly
GZ
galvanic
zinc
ZD
hot
zinc-dipped
A2
stainless
AISI304L
Product:
DZM 1 junction box holder1
Manufacturer:
ARKYS Ltd., Podstranska 1, 627 00 Brno
Technical features:
Material – steel or stainless steel sheet AISI 304 “A2”
Surface finish (finish) – cold galvanized
- hot zinc dipped by dipping
- stainless AISI 304 “A2”
Use:
The DZM 1 box holder serves to attach distribution boxes and other elements (sockets, switches, etc.) directly to the cable track.
Specifications:
Width – 95 mm
Height – 80 mm
Depth – 35 mm
Sheet thickness – 1,0 mm
Load capacity:
5 kg
Note: The declared load capacity depends on the professional assembly and correct anchor technique (use of appropriate anchoring elements according
to actual application).
Description:
The DZM 1 junction box holder is provided with tongues on the sides for fixation a cable tray by flexion one of tongues.
It is also provided with mounting holes on the front side of holder, which is designed for smooth fixing of distribution boxes and other
elements.
F
i
r
e
r
e
s
i
s
t
a
n
c
e
t
e
s
t
e
d
